ASP.Net Core Image Demo

List of Technology used in this Demo

  • ASP.NET Core 2.2 (Razor)
  • Entity Framework Core 2.2
  • Visual Studio Community (I am using 19, but this also work using 17)
  • SQL Server - I have it running in a Docker container on a Ubuntu VM (That said, this may work using any DBMS)

Steps to follow

These steps will vary with your setup and needs, so it may go without saying that this page should be used guide rather than an authoritative document

  1. Create Your Table
    1. For this example, I will use TSQL, however there is no reason that mySQL, PostgreSQL, or other relational DB should work just fine
    2. The most important bit is the data field that is of the VARBINARY(max) type
    3. My Example table setup is here:
      [ID] [uniqueidentifier] ROWGUIDCOL  NOT NULL,
[Name] [varchar](200) NOT NULL,
[Data] [varbinary](max) NOT NULL,
[Width] [int] NOT NULL,
[Height] [int] NOT NULL,
[ContentType] [varchar](50) NOT NULL,
[UplDate] [datetime] NOT NULL

ALTER TABLE [dbo].[ImageTB] ADD CONSTRAINT [DF_ImageTB_ID]
    DEFAULT (newid()) FOR [ID]
GO

ALTER TABLE [dbo].[ImageTB] ADD CONSTRAINT [DF_ImageTB_UplDate]
    DEFAULT (getdate()) FOR [UplDate]
GO
    4. I added some defaults, however in this example I set those values in code, so those are optional
  2. Create your VS project
    1. Select ASP.NET Core Web Application:
      New Project
    2. You can give the project any name
    3. Select Web Application:
      Web App
  3. Add NewGet Packages
    • EntityFrameworkCore
    • EntityFrameworkCore.Tools
  4. Connect the App to the DB
    1. I just used the Scaffold-DbContext command:
      Scaffold-DbContext "CS here" Microsoft.EntityFrameworkCore.SqlServer -OutputDir Models
    2. I did not make any edits to the Model file or the context file in the ASP project, however there is no reason that you can't do so
  5. Edit the index.chtml.cs file
    1. Update the OnGet method:
      // Declare a collection to make it available to the Razor Page
public List<ImageTb> ListOfImages { get; set; }

public async Task OnGet()
{
    // Connect to the DB
    using(var db = new imgTestContext())
    {
        //Retreive images from the DB
        ListOfImages = await db.ImageTb.OrderByDescending(d=>d.UplDate).ToListAsync();
    }
}
      1. I made mine async to aid in loading speed
      2. I added a simple LINQ query to retreive all images from the DB
    2. Add the Upload method:
      /// <summary>
/// Method to upload a file to the DB
/// </summary>
/// <param name="files">The file to upload</param>
/// <returns>Back to the index</returns>
public async Task<IActionResult> OnPostUploadAsync(IList<IFormFile>files)
{
    if (!ModelState.IsValid)
    return Page();

    IFormFile ui = files.FirstOrDefault();

    // Test to see if there is a file at all, and also if it is an image
    if (ui != null && ui.ContentType.ToLower().StartsWith("image/"))
    {
        using (var db = new imgTestContext())
        {
            // These three lines are the imporant bits
            MemoryStream ms = new MemoryStream();
            ui.OpenReadStream().CopyTo(ms);
            System.Drawing.Image image = System.Drawing.Image.FromStream(ms);

            // This is my way of extracting just the filename from the file
            FileInfo fi = new FileInfo(ui.FileName);

            // The rest of this is just standard EF
            var newImage = new ImageTb()
            {
                Id = Guid.NewGuid(),
                Name = fi.Name,
                Data = ms.ToArray(),
                Width = image.Width,
                Height = image.Height,
                ContentType = ui.ContentType,
                UplDate = DateTime.Now
            };

            db.ImageTb.Add(newImage);
            await db.SaveChangesAsync();
        }
    }

    return RedirectToPage("./Index");
}
  6. Edit the index.chtml file
    1. Remove everything
    2. Add in the code from my chtml file that you will find here:
      @page
@model IndexModel
@{
ViewData["Title"] = "Home page";
}

<div class="text-center">
<h1 class="display-4">Image Test</h1>
<p>This is a test</p>
</div>

<!--This is the FORM that invokes the OnPostUploadAsync method you see above-->
<div class="text-center">
<form method="post" enctype="multipart/form-data">
    Image: <input type="file" name="files" />
    <button class="btn btn-primary" asp-page-handler="upload">Upload</button>
</form>
</div>

<div>
<table class="table">
    <thead>
        <tr>
            <th>@Html.DisplayNameFor(model => model.ListOfImages[0].Data)</th>
            <th>@Html.DisplayNameFor(model => model.ListOfImages[0].Name)</th>
            <th>Length / Width</th>
            <th>@Html.DisplayNameFor(model => model.ListOfImages[0].ContentType)</th>
            <th>@Html.DisplayNameFor(model => model.ListOfImages[0].UplDate)</th>
        </tr>
    </thead>
    <tbody>
        @foreach (var myItem in Model.ListOfImages)
        {
            <tr>
                <!--This is the important bit for displaying the image data on the page-->
                @{
                    string imageBase64 = Convert.ToBase64String(myItem.Data);
                    string imgsrc =
                }
                <td><img src = "&imgsrc" alt = "@ myItem.Name" /></td>
                <td>@Html.DisplayFor(mi => myItem.Name)</td>
                <td>@Html.DisplayFor(mi => myItem.Height) /
                    @Html.DisplayFor(mi => myItem.Width)</td>
                <td>@Html.DisplayFor(mi => myItem.ContentType)</td>
                <td>@Html.DisplayFor(mi => myItem.UplDate)</td>
            </tr>
        }
    </tbody>
</table>
</div>
    3. If you have other edits from above, be sure to carry them over here
  7. Test
    • Upload an image to the DB:
      Test #1 - Dispaly the image
      Pre-Condition: Images are present in the DB
      Dependancies: That the app can reach the DB
      Step # Test Steps Test Data Expected Result Actual Result Status(Pass/Fail) Notes
      1 Turn on the app null Images will display
      Post Condition: The user should see any images that are in the db
    • Display image on the page:
      Test #2 - Upload a picture to the DB
      Pre-Condition: images are availabel to upload
      Dependancies: The app can reach in the DB
      Step # Test Steps Test Data Expected Result Actual Result Status(Pass/Fail) Notes
      1 Click the image select test.jpeg the path will be in the selection section
      2 click the upload button null the image will now be in the DB
      3 View the image list null Your image should appear
      Post Condition: The image will be saved in the DB and render on the page
  8. After everything is said and done you should have a web page that looks something like this:
    Results

Lastly, I know that the web page is not super artsy. However, this is a good a starting point as any. Feel free to reachout to me using the links below if there is any feedback.
